Vellamo Reveal Bath Filler Tap

Rated 4.86/5 from 7 customer reviews

Loading delivery estimate...

Klarna
Pay 3 interest-free instalments of £36.66 with Klarna Learn more about Klarna
Clearpay
Pay 4 interest-free instalments of £27.50 with Clearpay Learn more about Clearpay

What's great about it?

  • Uniquely styled deck-mounted bath mixer tap with contrasting modern angle design
  • Manufactured from reliable solid brass in a Polished Chrome finish that adds sleek appeal
  • Fitted ceramic disc cartridge valves for longevity and easy operation
  • Minimally shaped design makes for easier cleaning both of and around the mixer tap

Read full product description

Recommended extras

We've hand-picked these items because they are a great choice alongside the Vellamo Reveal Bath Filler Tap

The Reveal range from Vellamo is beautifully stylish, with soft curves contradicted by two angular lines running down the front of the tap bodies. Not only are these tap suitable for all water systems, even low pressure gravity, but they also come with a peace-of-mind 10 year guarantee. Lovely.

Features:
  • 10 year guarantee
  • Brass material
  • Polished chrome finish
  • Minimum water pressure of 0.2 bar
  • Easy to operate and clean
  • Bath waste sold separately - please see our recommended extras

Product Overview
Product Code VELRVL12
Type Bath Fillers, Bridge Bath Taps
Brand Vellamo
Brand Range Vellamo Reveal
GuaranteeMore information 10 Years

Guarantee

Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.


Features
AeratorMore information Yes
Material Brass
Number of Outlets 1 Outlet
Temperature Control Manual
Cartridge TypeMore information Ceramic Disc
Tap aerators are simple but beautifully-engineered devices that save water and money without a perceived loss of pressure. These small attachments are inserted inside the end of the spout and provide a regulated, smoothed and aerated flow of water by separating a single flow into many tiny streams. These streams mix with air as they flow from the tap, meaning less water is needed to achieve the same 'feel' and performance as non-aerated taps.

They can also be purchased separately and retrofitted to most taps, or they can usually be uninstalled if not wanted. They're a great benefit on high pressure systems where the full flow of water is unnecessary, cutting your water bills and helping to reduce wastage. On lower-pressure systems they can help to improve the performance of a tap by adding air to the limited flow of water available. All-in-all, they're pretty awesome.
Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.

Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.

Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.
Style
Mounting Type Deck Mounted
Finish Polished Chrome
Shape Round
Handle Type Dual Control, Lever
Spout Type Straight Spout
Texture Polished
Tap Holes 2 Holes
Style Modern
Dimensions
Height (mm) 151
Projection (mm) 111
Flow Rate
Flow Rate at 0.2 Bar (l/min) 11.3
Flow Rate at 0.5 Bar (l/min) 17.5
Flow Rate at 1 Bar (l/min) 26
Flow Rate at 2 Bar (l/min) 34
Flow Rate at 3 Bar (l/min) 36
Minimum Water PressureMore information 0.2

Minimum Water Pressure

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
