Butler & Rose Carlton Deck Mounted Bath Shower Mixer with Handset Kit

Rated 4.53/5 from 17 customer reviews

RRP £165 save 46%

£89.99 was £99.99

Loading delivery estimate...

Pay 3 interest-free instalments of £29.99 with Klarna Learn more about Klarna
Pay 4 interest-free instalments of £22.50 with Clearpay Learn more about Clearpay

What's great about it?

  • Deck-mounted bridge bath shower mixer with a classic design to suit traditional bathrooms
  • Manufactured from reliable solid brass in a Polished Chrome finish that adds sleek appeal
  • Fitted with quarter-turn ceramic disc cartridge valves for longevity and easy operation
  • Elegant front-facing crosshead valves with temperature indices increase ease of use

Read full product description

Recommended extras

We've hand-picked these items because they are a great choice alongside the Butler & Rose Carlton Deck Mounted Bath Shower Mixer with Handset Kit

The Butler & Rose Carlton bath shower mixer includes a matching single function shower handset and holder to give you that perfect bathing and showering experience. The traditional detailing on the tap and shower handset is stunning and will really stand out in your period style bathroom.

  • Wide-mouth spout
  • Traditional ABS plastic telephone shower handset
  • Handset cradle holder
  • Independent crosshead dual handles to control for hot & cold supply
  • White ceramic diverter lever
  • 1.5m stainless steel hose
  • 3/4" deck mounting unions
  • Made from solid brass
  • Chrome plated finish
  • Minimum 0.5 bar water pressure
  • Ceramic disc technology for a smooth and leak-free performance
  • 10 year guarantee
  • Waste sold separately - please see our recommended extras

  • Height - 226mm
  • Projection - 160mm
  • Pipe centres - 180mm
  • Width - 222mm

Product Overview
Product Code BRCAR05
Global Trade Item Number 5056585239347
Type Bath Shower Mixers, Bridge Bath Taps
Brand Butler & Rose
Brand Range Butler & Rose Carlton
GuaranteeMore information 10 Years


Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.

Material Brass
Number of Outlets 2 Outlets
Temperature Control Manual
Cartridge TypeMore information Ceramic Disc
Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.

Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.

Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.
Mounting Type Deck Mounted
Finish Chrome
Shape Round
Handle Type Crosshead, Lever, Triple Control
Spout Type Curved Spout
Texture Polished
Tap Holes 2 Holes
Style Traditional
Width (mm) 222
Height (mm) 226
Projection (mm) 160
Flow Rate
Flow Rate at 0.5 Bar (l/min) 10
Flow Rate at 1 Bar (l/min) 15
Flow Rate at 1.5 Bar (l/min) 19
Flow Rate at 2 Bar (l/min) 22.3
Flow Rate at 3 Bar (l/min) 28.2
Minimum Water PressureMore information 0.5

Minimum Water Pressure

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
