Harbour Status Matt Black 1 Outlet Concealed Thermostatic Shower Valve

No reviews yet - Write one

£149.99

Loading delivery estimate...

Klarna
Pay 3 interest-free instalments of £49.99 with Klarna Learn more about Klarna
Clearpay
Pay 4 interest-free instalments of £37.50 with Clearpay Learn more about Clearpay

What's great about it?

  • 1 outlet concealed design
  • Anti Calc thermostatic cartridge for effortless temperature control
  • Ceramic disc technology
  • Minimum water pressure: 0.5 bar
  • Interchangeable backplate design which allows portrait or landscape orientation
  • WRAS approved
  • 5 year guarantee

Read full product description

Recommended extras

We've hand-picked these items because they are a great choice alongside the Harbour Status Matt Black 1 Outlet Concealed Thermostatic Shower Valve

The single outlet matt black Harbour Status concealed shower valve is thermostatically controlled meaning that the water temperature will not vary from that which you've set, even if the pressure fluctuates or someone else in the house uses another tap. There's no more constantly fiddling with the controls trying to find and then keep the right temperature. You can just stand, relax and enjoy looking at the exquisite Matt Black finish.

The thermostatic control also prevents scalding and will automatically shutdown the valve should the hot or cold water supply fail. Not only that, but thermostatic controls have a built in safety limit, so should your child find themselves with free reign of the shower, they won't be able to turn the hot water high enough to injure them. The Status shower valve comes with 5 years guarantee.

Features:
  • Single outlet shower valve in an eye-catching Matt Black finish
  • Thermostatic valve with auto-shut off mechanism protects you from sudden changes in temperature, helping prevent scalding
  • Anti Calc thermostatic cartridge - advanced anti-debris technology that helps prevent blockage & limescale build-up for effortless temperature control
  • Ceramic disc technology prevents any unwanted leaks or drips
  • Interchangeable backplate design allows portrait or landscape orientation
  • Crafted from brass (valve body), stainless steel (backplate) & zinc alloy (handles)
  • Minimum water pressure required: 0.5 bar
  • Maximum 6.0 bar water pressure
  • Complies with BSEN 1111
  • WRAS approved
  • Covered by a 5 year manufacturer’s guarantee

Dimensions:
  • Height - 130mm
  • Width - 240mm
  • Depth - 131mm

Flow rates:
  • 0.5 bar (l/min): 11.1
  • 1.0 bar (l/min): 15.5
  • 1.5 bar (l/min): 18.9
  • 2.0 bar (l/min): 21.8
  • 3.0 bar (l/min): 26.5
  • 4.0 bar (l/min): 30.5
  • 5.0 bar (l/min): 33.8

Product Overview
Product Code HBSTAT55
Global Trade Item Number 5056585242132
Type Concealed Shower Valves
Brand Harbour
Brand Range Harbour Status
GuaranteeMore information 5 Years

Guarantee

Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.


Features
Number of Outlets 1 Outlet
Temperature Control Thermostatic
Cartridge TypeMore information Ceramic Disc
Popular Features WRAS approved
Taps use either a ceramic disc cartridge or a rubber compression washer to control flow. Rubber washers will naturally wear down with use, and the tap handle will require more and more rotations to turn on or off. On the plus side, it's very easy to replace a rubber washer and they're available everywhere.

Ceramic disc cartridges need only a 90-degree rotation to fully open or close, and the 2 ceramic plates are incredibly hard-wearing and resilient. They're more expensive to make, but they allow for a huge range of designs, easy operation and simple maintenance if needed.

Whilst it is rare for a ceramic cartridge to need replacing, you may very occasionally need to remove and rinse the cartridge if grit or debris within the water system is preventing the 2 plates from closing properly. Much like replacing a rubber washer, this is a quick and easy job, and will ensure many years of use.
Style
Mounting Type Wall Mounted
Finish Matt Black
Shape Square
Handle Type Square, Dual Control
Texture Matt
Style Modern
Orientation Portrait, Landscape
Dimensions
Width (mm) 240
Height (mm) 130
Depth (mm) 131
Flow Rate
Flow Rate at 0.5 Bar (l/min) 11.1
Flow Rate at 1 Bar (l/min) 15.5
Flow Rate at 2 Bar (l/min) 21.8
Flow Rate at 3 Bar (l/min) 26.5
Flow Rate at 4 Bar (l/min) 30.5
Flow Rate at 5 Bar (l/min) 33.8
Minimum Water PressureMore information 0.5

Minimum Water Pressure

Your water pressure depends on your home's water system. It’s important to consider water pressure when buying a new tap or shower. Buying a product with a minimum water pressure that’s too high for your home will result in poor performance.

- With a combi boiler you can usually expect between 1 and 2 bar

- With a gravity system (cold water tank in attic) you may have as little as 0.1 or 0.2 bar upstairs, and perhaps 0.5 bar downstairs

- With a high pressure unvented system (hot water cylinder, no cold water tank) you will generally have between 1 and 3 bar

You can install an item with a low minimum pressure rating on a high pressure system, but avoid installing an item with a high minimum rating on a low pressure system! Read our guide to water pressure to learn more.
