Geberit Duofix 980mm Frame & Alpha Concealed Cistern for Wall Hung Toilet

No reviews yet - Write one

Loading delivery estimate...

Pay in 3 interest-free payments of £59.99.
Klarna
Pay in 3 interest-free payments of £59.99. Learn more

What's great about it?

  • One-piece blow-molded leakproof design
  • Adjustable dual flush system to save water and reduce your bills
  • WRAS approved
  • Insulating polystyrene jacket helps to reduce condensation and enables silent water filling & discharging
  • Durable steel frame with weight capacity up to 400kg
  • 10 year manufacturer’s guarantee

Full details

Features:
  • Concealed cistern crafted from durable, tested materials for years of dependable use
  • One-piece blow-molded construction ensures no leaks as there are no joins for water to escape from
  • Insulating polystyrene jacket helps to reduce condensation and enables silent water filling & discharging
  • Adjustable dual flush system to save water and reduce your bills - preset to 5.8/3 litres as standard, and adjustable between 4.5/6/7.5l for the full flush and 3-4l for the half flush
  • Cistern operating pressure: 0.1 - 10 bar
  • WRAS approved
  • Meets EN 14055, Class II standards
  • Immediate post flush capability possible with factory settings - comes with required fill and flush valves for it to be operational immediately after installation
  • Easy maintenance - access all parts easily by removing the flush plate
  • Flush bend and water supply connection designed for easy installation
  • Water inlet location on the rear or top centre for easy installation
  • Powder-coated steel frame with Galvanised steel adjustable feet for added flexibility
  • Frame weight capacity: 400kg
  • Suitable for solid wall and plasterboard installations
  • Front actuation for a vertical flush plate installation
  • Supplied with straight pan connector and angled pan connector
  • Compatible with wall hung toilet pans with projection up to 620mm (sold separately)
  • Compatible with Geberit Alpha flush plates
  • Dual flush plate sold separately - please see our recommended extras
  • Trusted Geberit engineering ensures reliable and consistent performance
  • Covered by a 10 year manufacturer’s guarantee, with a 25 year spare parts guarantee (Geberit will continue to make and have available spare parts for the next 25 years from the date of sale)

Downloads
Technical Specifications
Product Overview
Product Code 458.036.00.2
Type Wall Hung Cistern Frames
Brand Geberit
Brand Range Geberit Alpha, Geberit Duofix
GuaranteeMore information 10 Years

Guarantee

Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.

If you need further info about a specific manufacturer's guarantee, please contact our team.


Features
Water Inlet LocationMore information Rear & Top Centre
Material Plastic, Steel
Popular Features Height Adjustable, WRAS Approved

Water Inlet Location:

This is the location where the mains water feed can connect to the cistern, when viewed from the front.
Cisterns that feature Bottom Left & Right inlets are usually supplied with a plug to seal the inlet which isn't used.

Style
Mounting Type Wall Mounted
Shape Square
Style Modern
Dimensions
Width (mm) 500
Height (mm) 980
Depth (mm) 120
Maximum Weight Capacity (kg) 400
