Features:
- Defined rectangular tubes offer a clean, geometric design for a modern look
- High heat output achieved through the larger surface area of the flat-faced heating bars
- Narrow 380mm width makes this a practical choice for heating rooms where wall space is limited
- Classic matt white finish provides a high-quality surface designed for its clean appearance and durability
- Crafted from high-grade mild steel ensuring exceptional heat conductivity and a reliable, steady output
- Radiator valves are sold separately, please see our recommended extras
- Fully EN 442 certified and CE/UKCA marked for verified safety and heat ratings you can trust
- Pressure tested at 1.3x to be more than a match for the demands of your home heating system
- Built in an ISO-certified factory with a focus on sustainable production and quality control
- 10 year guarantee
| Product Code | DES-183-WH |
|---|---|
| Global Trade Item Number | 5056880704694 |
| Type | Designer Radiators, Vertical Radiators |
| Brand | Toasty |
| Brand Range | Toasty Axis |
| Guarantee |
10 Years |
Guarantee
Please note that these guarantees are provided by the manufacturer, and will be subject to individual exclusions, exceptions, and terms and conditions, for example avoiding abrasive bleach-based cleaning products.
If you need further info about a specific manufacturer's guarantee, please contact our team.
| Number of Columns | Single Panel |
|---|---|
| Number of Sections | 10 Sections |
| Number of Tubes | 10 Tubes |
| Material | Steel |
| RAL Code |
9016 |
|---|---|
| Mounting Type | Wall Mounted |
| Finish | White |
| Shape | Flat Panel |
| Texture | Matt & Satin |
| Style | Modern |
| Orientation | Vertical |
RAL Codes
RAL codes are used to define colours for paints & coatings. The codes are very specific, so two shades of blue will have a completely different RAL code. The codes can be useful if you want to ensure two different products will be a colour match.
Some of our heating products can be purchased in bespoke colours chosen from a selection of RAL codes. If you are interested in this service please contact our sales team here.
| Pipe Centres (mm) |
380 + valves |
|---|---|
| Width (mm) | 380 |
| Height (mm) | 1800 |
| Depth (mm) | 111 |
| Wall to Face (mm) | 111 |
| Wall Distance (mm) | 20 |
| Tube Diameter (mm) | 20 |
| Wall to Pipe Centres (mm) | 44 |
| Projection (mm) | 111 |
| Inlet Location | Side |
Pipe centres are measured between the centres of the two heating pipes connecting to your radiator valves. For side connection radiators, valve dimensions vary by model and can affect the final distance required. Please account for your chosen valve measurements when planning installation.
| Fuel Source | Central Heating |
|---|---|
| Heat Output (BTU∆t 50ºC) | 4038 |
| Heat Output (Watts∆t 50ºC) | 1183 |
| Heat Output (BTU∆t 30ºC) |
2079 |
| Heat Output (Watts∆t 30ºC) |
609 |
BTU (British Thermal Units) is a measure of the heat output of radiators. BTU ∆t 30ºC is an indication of the output in BTU your radiators will give you at this standard temperature. To find out the BTU you need for rooms in your home, take a look at our BTU Calculator.
Watts is a measure of heat output used for electric radiators, with a higher watt figure meaning a higher heat output. Purchasing a radiator that has the correct wattage will ensure your room will be at a comfortable temperature without wasting energy.
By using our BTU Calculator,you can calculate the number of watts your radiator needs to adequately heat your room.
